DWR-2000M (D1)
5G AX3000 CPE Router with LCD Display
DWR-2000M (B1)
5G AX3000 CPE Router
- Next generation 5G connectivity speeds up to 4.67 Gbps (theoretical value)
- Built-in Wi-Fi AX3000 distributes high-speed, high-performance Wi-Fi to all your connected devices
- Dual-band Wi-Fi with MU-MIMO technology makes 4K streaming, VR gaming or video chatting a breeze
- 2.5 Gigabit Ethernet WAN/LAN port and 2.5 Gigabit Ethernet LAN port
- Connect up to 512 devices to your home Wi-Fi network
- Latest Wi-Fi security with 128-bit encryption
- Also available as hardware version D1: DWR-2000M (D1)
DWR-2000M (B1)
Specifications
| Device Interfaces | 1 x 10/100/1000/2500 Gigabit Ethernet LAN Port, 1 x 10/100/1000/2500 Mbps Gigabit Ethernet WAN/ LAN port, 1 x USB Type C Port, 1 x LTE SIM/USIM Slot, 1 x Reset Hole, 1 x WPS Button, 1 x Power Button, 1 x RJ11 |
|---|---|
| LED | Power, WLAN, 4G LTE, 5G |
| Antenna Type | 2 x 3dBi Internal 2.4G & 5G Dual Band Antenna, Internal 4G/5G Antennas |
| Wi-Fi Data Rate (theoretical value) | 2T2R 2.4GHz 802.11b/g/n / ax, 574 Mbps 2T2R 5.8GHz 802.11a/n/ac/ax, 2402 Mbps @ 160Mhz |
| Wireless IEEE Standard | 802.11a/b/g/n/ac/ax |
| WAN Interface | DHCP Static IP PPPoE (PPPoE Pass-through) |
| Security Protocol | WEP (128bits), 802.11i 128-bit TKIP/AES |
| Firewall | DoS, IP/MAC Address Filtering |
| Device Management | Web UI |
| Hardware version | B1 |
| Size | (L*W*H) 107*107*185mm |
| Weight | 690g |
| Power Input | 12 V 2 A |
| Operating Temperature | -10 to 40 °C |
| Storage Temperature | -40 to 70 °C |
| Operating Humidity | 10% to 90% non-condensing |
| Certifications | CE, RoHS |
| 5GNR Sub6 GHz | N1/3/5/7/8/20/28/38/N40/41/77/78 |
| LTE Cat20 FDD | B1/B3/B5/B7/B8/B20/B28/B42/B43 |
| LTE Cat20 TDD | B38/B40/B41 |
| WCDMA | B1, B5, B8 |
Actual performances may vary due to settings, cabling, temperature, network configuration, interface, device compatibility, environmental and on-site conditions, and other similar factors. References to power capability, signal or processing speed, signal range or distance, data encryption, storage capacity, display properties, or other performance metrics are based on optimal conditions derived from industry standards and provided for informational purposes only. Specifications may be subject to change without prior notice.
