18-Port Gigabit PoE Easy Smart Switch highlights 16 Ports GE PoE Ethernet for downlink; 2 Ports 1G Combo for uplink.
DGS-1100-18PV2
18-Port Gigabit PoE Easy Smart Switch
- 16 Ports GE PoE Ethernet for downlink
- 2 Ports 1G Combo for uplink
- PoE IEEE 802.3af/at options, power budget 130W
- 1 smart fan
- Broadcast/Multicast/Unicast Storm Control
- 802.3ad / 802.1AX Link Aggregation
- 802.1D STP/ 802.1w RSTP
- IGMP Snooping
- Nuclias Unity
- SSL support
Overview
DGS-1100-18PV2
Specifications
| Interfaces | 16 x GE PoE 2 x 1G Combo |
|---|---|
| Switching Capacity | 36 Gbps |
| Max. Packet Forwarding Rate | 26.78 Mpps |
| PoE Standards | IEEE 802.3af/at |
| PoE Power Budget | 130 W |
| Max Power Consumption | 166.7 W (PoE on) 18.3 W (PoE off) |
| Dimensions | 280 x 230 x 44 mm |
| Weight | 2.1 kg |
| FAN | 1 Smart Fan |
| Operating Temperature | -5°C to 50°C (23°F to 122°F) |
| Storage Temperature | -40°C to 70°C ( -40°F to 158°F) |
| Operating Humidity | 0% to 95% non-condensing |
| Storage Humidity | 0% to 95% non-condensing |
| Power Supply Type | Internal |
Actual performances may vary due to settings, cabling, temperature, network configuration, interface, device compatibility, environmental and on-site conditions, and other similar factors. References to power capability, signal or processing speed, signal range or distance, data encryption, storage capacity, display properties, or other performance metrics are based on optimal conditions derived from industry standards and provided for informational purposes only. Specifications may be subject to change without prior notice.
