The DIR-X3010 is a Multi Gigabit Wi-Fi 6 Mesh Router that offers simultaneous dual-band connections, with wireless speeds of up to 2400 Mbps on the 5 GHz band and 574 Mbps on the 2.4 GHz band. It is a dual-band wireless router for home users and smart home networking, delivering high performance across different network applications and letting more devices transmit data at the same time.
DIR-X3010
AX3000 Multi Gigabit Mesh Router
- 3 Gbps Dual-Band WiFi 6: Empowers your devices to operate at their maximum speed. Delight in seamless 4K streaming, immersive AR/VR gaming, and rapid downloads.
- 2.5G Port: 1x 2.5 Gbps WAN port and 3x 1Gbps LAN ports with link-aggregation offer high-speed data transmissions. This setup surpasses the 1G bottleneck, propelling your devices to optimal performance levels.
- Enhanced Coverage: Utilizing 5x high-power external antennas combined with Beamforming, our system offers increased capacity, robust and reliable connections, and reduced interference.
- Mesh Compatibility: Seamlessly integrates with Mesh routers to create a unified Mesh WiFi network throughout your home, ensuring uninterrupted connectivity and eliminating drops or lag when transitioning between signals.
- Advanced Parental Controls: Protect your kids online with instant monitoring, content filters and customized settings for every connected device.
- Easy Setup and Use: Managing your network is now simpler than ever with the D-Link Wi-Fi Assist App.
Overview
2.5G Multi-Gig WAN
Unlock unparalleled device performance with lightning-fast data transfers through the 2.5GE port, harnessing the full potential of Wi-Fi 6.
Dual Core Processor
The powerful dual-core CPU ensures smooth operation, while its ability to connect to more devices across dual bands ensures efficient performance.
Smart Roaming
Seamlessly connects your devices to the strongest signal as you move from room to room, eliminating the need for them to disconnect and reconnect.
OFDMA
Small data packets destined for multiple devices are transmitted together and never have to queue up again. Perfect for Smart Homes filled with bandwidth-hungry IoT devices battling for bandwidth.
Expandable Network
DIR-X3010 is a scalable solution. Add extra DIR-X3010 Points where you need more coverage.
DIR-X3010
Specifications
| CPU frequency | 1.3 GHz Dual-Core |
|---|---|
| Memory | 512MB DDR4 |
| Flash | 128MB Nand Flash |
| Wi-Fi | 2T2R 2.4GHz 802.11b/g/n/ac/ax 574Mbps¹ 2T2R 5GHz 802.11a/n/ac/ax 2400Mbps¹ |
| Device Interfaces | 1 x RJ45 10M/100M/1000M/2.5G WAN Ethernet 3 x RJ45 10M/100M/1000M LAN Ethernet 1 x Reset Button 1 x WPS Button |
| Wi-Fi Antenna | 2 x 5dBi External 2.4GHz antennas 3 x 5dBi External 5GHz antennas |
| Standard | 802.11b/g/n/ac/ax 574Mbps¹ 2.4GHz 802.11a/n/ac/ax/ 2400Mbps¹ 5GHz |
| Modulation schemes | OFDM = BPSK,QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM DSSS = DBPSK, DQPSK, CCK |
| Transfer Rate | HE20: up to 574Mbps¹ 2.4G+5G HE40: up to 1148Mbps¹ 2.4G+5G HE80: up to 1200Mbps¹ 5G HE160: up to 2400Mbps¹ 5G |
| WAN Type | Static IP Dynamic IP PPPoE 802.1p & 802.1q VLAN tagging |
| Security Protocol | WPA/WPA2 - Personal WPA2 - Personal WPA2/WPA3 - Personal (WPS not supported) WPA3 Only (WPS not supported) |
| Firewall | DoS Stateful Packet Inspection Anti-spoofing checking IP/MAC address filtering 1 x DMZ |
| Mesh | D-Link Wi-Fi Mesh |
| QoS | D-Link Intelligent QoS Technology |
| Power Saving | Target Wake Time (TWT) |
| Access Control | Advanced Parental Controls Guest zone |
| Dynamic DNS | No-IP DDNS Dyn DDNS |
| Protocols | IPv4 IPv6 |
| Operation Modes | Router mode Bridge mode Extender mode AP Mode |
| VPN Pass-Through | L2TP OpenVpn PPTP |
| Operating Temperature | 0°C~40°C |
| Storage Temperature | -20°C ~ 70°C |
| Operating Humidity | 5%~95% (typical) |
| Power Supply | 12V/1A |
| Dimensions | 221.5 x 147.1 x 38.5 mm |
| Regulation Compliance | CE |
| Safety Regulations | UL |
| Green Standard | RoHS |
Actual performances may vary due to settings, cabling, temperature, network configuration, interface, device compatibility, environmental and on-site conditions, and other similar factors. References to power capability, signal or processing speed, signal range or distance, data encryption, storage capacity, display properties, or other performance metrics are based on optimal conditions derived from industry standards and provided for informational purposes only. Specifications may be subject to change without prior notice.
