The DWR-932M 4G/LTE Mobile Router is a 4G/LTE Cat4 high speed broadband wireless WAN (WWAN) to Wi-Fi mobile hotspot. The DWR-932M uses a 4G Internet connection to give you an easy-to-deploy Wi-Fi network anywhere you need one. Instead of limiting your mobile Internet connection to a single device through a USB dongle, the DWR-932M allows you to create a Wi-Fi hotspot to share your connection. The convenient size means you can share your connection anywhere; use it in a cafe to send e-mail while your friend reads the news, or at the airport so you and your coworkers can work while waiting for your plane.
DWR-932M
4G LTE Battery Mobile Wi-Fi Router with LCD Display
- Uses a SIM card to connect to the Internet
- Compatible with 802.11n/g/b wireless devices
- Micro-USB port for easy charging
- 3000mAh so you stay connected longer
- Small size lets you drop it in a purse or pocket and take it wherever you go
- LCD display gives you current status at a glance
- Industry Standard WPA/WPA2 Wi-Fi security protocol
- Built-in firewall
- Wi-Fi Protected Setup (WPS) for one-touch setup
Overview
Connect Anywhere
Simply insert your data-enabled SIM card to set up your very own mobile Wi-Fi network. The DWR-932M is perfect for when you need to quickly set up an impromptu network. It’s ideal for business trips when you need to share an Internet connection with everybody during a meeting, or use it for travel, allowing you to provide all your travel companions with Internet access.
Easy to Set Up
Sharing your Internet connection doesn’t have to be a complicated process - just open a web browser to access D-Link’s modern, user-friendly graphical web interface. The setup wizard’s easy to use step-by-step instructions will have your network up and running in minutes. Implement WPA/WPA2 wireless encryption in minutes with the wireless network setup wizard, or use Wi-Fi Protected Setup (WPS), which establishes a connection to new devices with the touch of a button.
Flexible Usage
The DWR-932M 4G/LTE Mobile Router gives you instant connectivity, all in a powerful yet portable device, that fits easily into your pocket. The rechargeable 3000 mAh Li-ion battery allows you to stay connected for long periods of time, and it’s plug-and-play with no complicated software to install. Getting online with the DWR-932M is quick, easy, and convenient.
DWR-932M
Specifications
| Frequency Support¹ | LTE Mode: Category 4: Band 1/3/5/7/8/20/28/38/40/41 WCDMA/HSPA/HSPA+/DC-HSPA Mode: Band 1/5/8 |
|---|---|
| Data Throughput² | LTE Mode: Downlink: 150 Mbps Uplink: 50 Mbps WCDMA/HSPA/HSPA+ Mode: Downlink: 21 Mbps Uplink: 5.76 Mbps |
| Security | WPA/WPA2 PSK Auto (TKIP/AES) WPS Push-Button Connection |
| Advanced Functions | Built-in firewall UPnP Built-in NAT |
| Wi-Fi Data Rates² | Up to 300 Mbps with 802.11n clients 1/2/5.5/11 Mbps in 802.11b mode 6/9/11/12/18/24/36/48/54 Mbps in 802.11g mode |
| Wireless Security Features | WPA/WPA2 PSK Auto (TKIP/AES) WPS Push-Button connection |
| Firewall | Network Address Translation (NAT) |
| Advanced Features | Port/Application Forwarding USSD support Universal Plug And Play (UPnP) MicroSD mass storage IP filter Supports local updates, FOTA SMS messaging |
| Interfaces | 802.11n/g/b wireless LAN Single NANO Sim |
| Antenna | Internal cellular antennas (1T2R) Internal Wi-Fi antennas |
| Display | LCD Display Internet connection status Network type Carrier Signal strength Battery status Roaming status Wi-Fi & security status SMS & SMS status Wi-Fi clients |
| Power | DC 5 V/1A Rechargeable 3000 mAh Li-ion battery |
| Dimensions | 108 x 63 x 15.5 mm |
| Weight | 136 g |
| Operating Temperature | 0 to 40 ˚C |
| Storage Temperature | -30 to 70 ˚C |
| Operating Humidity | 10% to 90% (non-condensing) |
| Certifications | CE RoHS |
Actual performances may vary due to settings, cabling, temperature, network configuration, interface, device compatibility, environmental and on-site conditions, and other similar factors. References to power capability, signal or processing speed, signal range or distance, data encryption, storage capacity, display properties, or other performance metrics are based on optimal conditions derived from industry standards and provided for informational purposes only. Specifications may be subject to change without prior notice.
