D-Link

MS60

AX6000 Wi-Fi 6 IoT Gateway

  • Matter-certified¹
  • All-in-One Router & IoT Gateway
  • Wi-Fi 6 technology provides faster speeds, greater capacity and less network congestion
  • Superior Wi-Fi 6 performance with speeds of up to 6 Gbps² for seamless video streaming, gaming and video calls
  • Four Gigabit Ethernet LAN ports and one 2.5 Gigabit Ethernet WAN port allow for high-speed wired connectivity
  • D-Link’s AI algorithm optimizes your Wi-Fi for more stable and reliable connections
  • Bluetooth-enabled for convenient device setup
  • Free AQUILA PRO AI app for hassle-free installation and management
Where to buyDownload datasheetView specifications

Overview

User Benefits

  • Matter Certification: Works with other Matter-compliant devices¹
  • Environmentally Friendly: Casing made with post-consumer recycled materials, green packaging, and efficient ventilation
  • AI Traffic Optimizer: AI-based QoS technology enables uninterrupted network experience for important applications
  • AI Wi-Fi Optimizer: Automatically keeps you on the optimal channel to eliminate interference
  • 2.5 Gigabit Port: Perfect for homes with multiple devices requiring a reliable connection for bandwidth-intensive activities
  • Simple Setup and Management: Set up your mesh Wi-Fi, D-Link and Matter-certified smart devices in minutes with the AQUILA PRO AI app to effortlessly manage your smart home
  • Enhanced Security: Advanced parental controls, guest Wi-Fi, WPA3™ encryption and IEC 62443-4-1 for safer connections
  • 360° Spherical Coverage: Say goodbye to weak signals and dead zones. Harness our advanced antenna design for seamless Wi-Fi

MS60

Specifications

Specification
Device Interfaces4 x Gigabit Ethernet LAN port 1 x 2.5 Gigabit Ethernet WAN port 1 x WPS button 1 x Reset button 1 x Power connector 1 x Power on/off button 1 x LED on/off
LEDPower/Status/WPS
Antenna Type4 x Wi-Fi dual-band internal antennas 1 x BLE internal antenna 4 x Wi-Fi 5 GHz internal antennas
Wi-Fi Data Rate²2.4 GHz up to 1148 Mbps 5 GHz up to 4804 Mbps
Wireless StandardsBLE 5.3 (Bluetooth Low Energy) Thread 1.3
IEEE StandardIEEE 802.11ax/ac/n/g/b/k/v/a/h IEEE 802.3u/ab/bz
WAN TypeStatic IP Dynamic IP PPPoE PPTP L2TP DS-Lite 802.1p & 802.1q VLAN tagging and priority bit
Security ProtocolWPA/WPA2 - Personal WPA2 - Personal WPA2/WPA3 - Personal (WPS not supported) WPA3 Only (WPS not supported)
FirewallDoS Stateful Packet Inspection Anti-spoofing checking IP address filtering 1 x DMZ
MeshD-Link Wi-Fi Mesh
QoSD-Link Intelligent QoS Technology
Power SavingTarget Wake Time (TWT)
Access ControlAdvanced Parental Controls Guest zone
Dynamic DNSNo-IP DDNS Dyn DDNS
ProtocolsIPv4 IPv6
Operation ModesRouter mode Extender mode Bridge mode
VPN Pass-ThroughL2TP PPTP IPSec
Device ManagementAQUILA PRO AI app (iOS and Android) Web UI
Voice AssistantsAmazon Alexa Google Assistant
Hardware VersionA1
Dimensions156 x 188.7 x 116 mm (6.14 x 7.43 x 4.57 in)
Weight516 g (18.2 oz)
Power Input12V / 2A
Max Power Consumption24 W
RF Output Power2.4 GHz - 100 mW/20 dBm 5 GHz - 100 mW/20 dBm
Operating Temperature0 to 40 °C (32 to 104 °F)
Storage Temperature-20 to 65 °C (-4 to 149 °F)
Operating Humidity10% to 90% non-condensing
Storage Humidity5% to 95% non-condensing
CertificationsCE FCC IC

Actual performances may vary due to settings, cabling, temperature, network configuration, interface, device compatibility, environmental and on-site conditions, and other similar factors. References to power capability, signal or processing speed, signal range or distance, data encryption, storage capacity, display properties, or other performance metrics are based on optimal conditions derived from industry standards and provided for informational purposes only. Specifications may be subject to change without prior notice.
